1/8" ro 1 " npt pipe taps w / storage case - $100 (Northlake)
QR Code Link to This Post
Material High-Speed Steel
Number of Pieces 6
Pipe Size 1/8, 1/4, 3/8, 1/2, 3/4, 1
Thread Type NPT
Chamfer Type Plug
Number of Flutes 4, 5
Container Type Wood Case
Shank Type Square
Drill Bit
Size 7/16", 9/16", 45/64", 29/32", 1 9/64", Q
Decimal Equivalent 0.332", 0.4375", 0.5625", 0.7031", 0.9063", 1.1406"
Finish Uncoated
Flute Type Straight
For Use On Aluminum, Brass, Bronze, Copper, Iron, Nickel, Plastic, Stainless Steel, Steel
Maximum Tapping Depth 3/4", 1 1/16", 1 3/8", 1 3/4"
Number of Tapping Ends 1
Overall Length 2 1/8", 2 7/16", 2 9/16", 3 1/8", 3 1/4", 3 3/4"
Tap Sizes Included 1/8, 1/4, 3/8, 1/2, 3/4, and 1
Thread Length 3/4", 1 1/16", 1 3/8", 1 3/4"
Threads per Inch 11 1/2, 14, 18, 27
Country of Origin United States
DFARS Compliance Specialty Metals COTS-Exempt
Export Control Classification Number (ECCN) EAR99
REACH Compliance REACH (EC 1907/2006) (11/07/2024, 242 SVHC) Compliant
RoHS Compliance RoHS 3 (2015/863/EU) Compliant
Schedule B Number show contact info
U.S.–Mexico–Canada Agreement (USMCA) Qualifying No
A range of sizes for adding internal threads to pipe and conduit. These taps can also be used to thread components like manifolds. They have straight flutes that are good for most jobs.
High-Speed Steel—The most versatile taps resist heat and wear to stay sharp. They’re good for most metals and plastic. These taps resist heat and wear to stay sharp.
Uncoated—The economical choice, these won't last as long as coated taps.
Mc Master price $375
